SK92672.1A /3D-90LH/4 3D TF - Nord United States Sales

BRAND	Nord
Product	SK92672.1A /3D-90LH/4 3D TF
Description	Bevel helical geared motor
Internal code	ONR4014364
Weight	38
Technical specification	Alternative for the SK92672AX / 3D-90 L / 4 3D TF from the serial number 1005477504.00 Product name bevel helical geared motor Gearbox ATEX version Gearbox ATEX COMPLIANT 3D EX code gear dust II 3D Ex h IIIC T125 ° C Dc Motor type II 3D Ex tc IIIB T125 ° C DcX Engine speed 1,420 rpm Translation 30.67 Output speed 46,000 1 / min Service factor 1.00 Output torque M2 (Nm) 309.00 Max. Output torque M2 max. (Nm) 318.00 Power (kW) 1,500 Voltage (V) 230/400 Frequency (Hz) 50 Efficiency class IE2 Operating mode S1 Motor protection class IP55 Insulation class F Nominal current 1 (AMP) 5.85 Nominal current 2 (AMP) 3.38 Cosine 1 0.79 Surface temp. Motor in ° C 125 Gearbox design M1 Housing type hollow shaft Shaft dimension 35H7 Vent Pressure vent Thermal motor protection PTC thermistor ATEX mains / converter operation Mains operation Connection type star Terminal box position / cable insert 1 / I Type of lubricant mineral oil ISO VG 220 Class oil CLP 220 Lubricant quantity (l) 0.850 Painting instructions old Without painting Painting instructions Without painting Atex calculation SP-200821-1000-0591 Typ./term. GTS + MTS + KK Std (VA) CE logo yes CCC Logo No. UL no CSA no DoE CC No. CSA ev no Alto Rendimento No. Korea Energy Label No.

Please Contact Us to Order to offer best price and delivery time for Nord - SK92672.1A /3D-90LH/4 3D TF Bevel helical geared motor number, also you may ask some other model number is well. We can offer best price, and delivery time with wide products distribution network in United States Industrial products Market.

WE SELL ONLY ORIGINAL AND NEW PRODUCTS!

Our company is not an authorized distributor and manufacturer's representative of the brands shown on the website. Private brand names shown on this site and trademarks are the property of their respective owners

Important note: Although we Nord - Products are Onrion LLC not an authorized dealer. All rights are reserved by the manufacturers and their official partners.

Where can I buy SK92672.1A /3D-90LH/4 3D TF by Nord in United States?

You can purchase SK92672.1A /3D-90LH/4 3D TF by Nord from Onrion LLC. We serve customers across United States, offering competitive prices and reliable service.

What is the price of the SK92672.1A /3D-90LH/4 3D TF?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of Nord in United States?

While we are not the official distributor or seller of Nord in United States, we source our products from reliable channels and offer you original Nord equipment at competitive prices.

How can I access SK92672.1A /3D-90LH/4 3D TF catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for SK92672.1A /3D-90LH/4 3D TF on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for SK92672.1A /3D-90LH/4 3D TF?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
