part no:DCX22L GB KL 18V - Maxon United States Sales

BRAND	Maxon
Product	part no:DCX22L GB KL 18V
Description	DC motor
Internal code	ONR4802253
Technical specification	GPX22 A 28:1 gearbox VALUES AT NOMINAL VOLTAGE Nominal voltage 18 V No load speed 11800 rpm No load current 54.6 mA Nominal speed 10800 rpm Nominal torque (max. continuous torque) 32.2 mNm Nominal current (max. continuous current) 2.26 A Stall torque 386 mNm Stall current 26.5 A Max. efficiency 91 % CHARACTERISTICS Terminal resistance 0.68 Ω Terminal inductance 0.0779 mH Torque constant 14.6 mNm/A Speed constant 654 rpm/V Speed / torque gradient 30.5 rpm/mNm Mechanical time constant 3.13 ms Rotor inertia 9.82 gcm² THERMAL DATA Thermal resistance housing-ambient 13.6 K/W Thermal resistance winding-housing 4.57 K/W Thermal time constant winding 23.4 s Thermal time constant motor 646 s Ambient temperature -40...+100 °C Max. winding temperature +125 °C MECHANICAL DATA Bearing type Waelzlager Max. speed 18000 rpm Axial play 0 mm, at radial load < 2.5 N 0.1 mm, at radial load > 2.5 N Radial play 0.02 mm Max. axial load (dynamic) 2.5 N Max. force for press fits (static) 30 N (static, shaft supported) 440 N Max. radial load 16 N, 5 mm from flange OTHER SPECIFICATIONS Number of pole pairs 1 Number of commutator segments 9 Number of autoclave cycles 0 PRODUCT Weight 95 g

Please Contact Us to Order to offer best price and delivery time for Maxon - part no:DCX22L GB KL 18V DC motor number, also you may ask some other model number is well. We can offer best price, and delivery time with wide products distribution network in United States Industrial products Market.

WE SELL ONLY ORIGINAL AND NEW PRODUCTS!

Our company is not an authorized distributor and manufacturer's representative of the brands shown on the website. Private brand names shown on this site and trademarks are the property of their respective owners

Important note: Although we Maxon - Products are Onrion LLC not an authorized dealer. All rights are reserved by the manufacturers and their official partners.

Where can I buy part no:DCX22L GB KL 18V by Maxon in United States?

You can purchase part no:DCX22L GB KL 18V by Maxon from Onrion LLC. We serve customers across United States, offering competitive prices and reliable service.

What is the price of the part no:DCX22L GB KL 18V?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of Maxon in United States?

While we are not the official distributor or seller of Maxon in United States, we source our products from reliable channels and offer you original Maxon equipment at competitive prices.

How can I access part no:DCX22L GB KL 18V catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for part no:DCX22L GB KL 18V on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for part no:DCX22L GB KL 18V?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
