| BRAND | Badger Meter |
| Product | RCDL M25 1" 1,4571 Vectra Viton ohne Impulsgeber |
| Internal code | ONR4626938 |
| Weight | 1 |
| Technical specification | liquid flow meter RCDL M25 in stainless steel version without construction. materials and technical data; Case/Back: stainless steel 1.4571 Measurement chamber: Vectra (LCP plastic) O-rings: Viton Measuring range: 3-100 l/min Measurement accuracy: +/- 1.5% of value p-max: 16 bar t-max: 120 °C Connection: R 1" outside, BSP Installation length: 190 mm Installation position: horizontal, standing Product no. 140955 |
Please Contact Us to Order to offer best price and delivery time for Badger Meter - RCDL M25 1" 1,4571 Vectra Viton ohne Impulsgeber number, also you may ask some other model number is well. We can offer best price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY ORIGINAL AND NEW PRODUCTS!
Our company is not an authorized distributor and manufacturer's representative of the brands shown on the website. Private brand names shown on this site and trademarks are the property of their respective owners
Important note: Although we Badger Meter - Products are Onrion LLC not an authorized dealer. All rights are reserved by the manufacturers and their official partners.
Where can I buy RCDL M25 1" 1,4571 Vectra Viton ohne Impulsgeber by Badger Meter in United States?
You can purchase RCDL M25 1" 1,4571 Vectra Viton ohne Impulsgeber by Badger Meter from Onrion LLC. We serve customers across United States, offering competitive prices and reliable service.
What is the price of the RCDL M25 1" 1,4571 Vectra Viton ohne Impulsgeber?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Badger Meter in United States?
While we are not the official distributor or seller of Badger Meter in United States, we source our products from reliable channels and offer you original Badger Meter equipment at competitive prices.
How can I access RCDL M25 1" 1,4571 Vectra Viton ohne Impulsgeber catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for RCDL M25 1" 1,4571 Vectra Viton ohne Impulsgeber on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for RCDL M25 1" 1,4571 Vectra Viton ohne Impulsgeber?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
9008527MID M 1000 mit Flansch DN 50 ST 37
MID M 1000 with flange DN 50 ST 37 Hard rubber Hastelloy C 230VAC Magnetic-inductive flowmeters Type "Magneto Flow M1000 AM". Transducer: Type II Process connection: flange EN 1092-1 / St. 37 DN / PN: 50/16 * Measuring range: 3.6 to 1200 l / min Installation length: 225 mm Lining: hard rubber Max. Temp. 80 ° C Electrodes: Measurement and idle electrodes Elec Material: Hastelloy C Housing: St. 37 painted gray Transmitters: Type M1000 AM Assembly: Assembled version Software language: English / German * Units: Metric Current output: 0 / 4-20 mA * Endwertskala: standard (2.5 m / s) Pulse output: 24 V DC active / passive * Pulse rate: 1 PPL LCD display: 4 lines Read flow: 8 digits (unidirectional / bidirectional) 2 totalizers: 14 digits Protection: IP 67 Power supply: 92 to 275 VAC Min.Leitfähigkeit: 5 microS / cm Accuracy: +/- 0.3% of the measured value
ELECTRODES, WITH METER MOUNTED PRIMO AMPLIFIER, 316 SS GROUNDING RINGS
SN: 0506-067 0-75 meters for DN 50 Electromagnetic Flowmeter 3 x (2 x 0.25 mm²) + Ground of 160 Ω / km
MID M 1000 flange ISO DN 100 PN 16 Hard rubber Hastelloy C 230VAC
MID M 1000 with ISO flange DN 150 Hard rubber Hastelloy C 230VAC
LIQUID FLOW METER RCDL M70, WITH PULSE GENERATOR PFT-1E.
Body: Bronze Measuring chamber: Vectra O-rings: Viton Measuring range: 18 - 265 l / min Accuracy: + / - 1.5% of the value p-max: 16 bar t-max: 120 ° C Connection: R 1 1/4 "male Length: 273 mm Mounting position: horizontal, vertical Pulse Output: Transistor NPN open Scale Factor: 0.00001 to 0.9999 Supply: 12-24 VDC
for petrol, oil, digital and electronic counters, rotary platforms ½, flow. 0-28 I / min
Product preset Max 120°F/50°C Min 20°F/-5°C 868 mhz
Einbauzähler mit Impulsgeber für Schmieröl
ELECTROMAGNETIC FLOW METER
MAGNETOFLOW TYP II DN 65 / PN 16
Magnetic flowmeter with transmitter M1500 for full pipes.
MID 2-100/16-F/ST-WG-ML/HC-ST M15A SK1
Type II DN 100 / PN 16 with amplifier M1500 for full pipes
MID 2-25/16-F/ST-HG-MEL/HC-ST M15D obsolete, replacement MID 2-25/16-F/St-HG-MEL/HC-St M10DM
(P/N 9005257) M1500 (24 VDC)
MID M 1000 MIT FLANSCH DN 32 HARTGUMMI HASTELLOY C 24VDC
Magnetic flowmeter Magneto Flow Type II DN 32 / PN 16 with transmitter for M2000 full pipes.
schetchik jidkosti
MN SERİES,70-733 LPM 1200 KPA 3”/80MM BSP
BADGER METER RCDL DISC METERS POSITIVE DISPLACEMENT – NUTATING DISC
Register with pulse output, Electronic counter LCR type with an LCD display and, pulse output above for OG-Baureihe.Anzeige 1: resettable totalizer or flow indication programmable, Format xxxx.x. Display 2: Non-resettable totalizer, 14 digits. Memory display: EEPROM, data retention in battery replacement Units: liters, gallons, pints, quarts Temperature: 0-70 ° C Pulse acquisition: Reed, max.50Hz Input pulse: from 1.00 to 17000.00 (numerator) Correction factor: 0.5000 to 2.0000 Power supply: 3 VDC Lithium CR 1/2 AA Protection: IP 64 For counter Size: M25-M35-M40-M70-M120-M170 Pulse output: NPN, MOSFET 40V / 2A Pulse factor: 0.01-99.99 Pulse length: 10ms (2ms, 20ms, 40ms) Ext.Stromversorg. : 8-24VDC Pulse output PPL: 0,01-0,1-1-10-100 Dosing control: 0.01 to 999.99 Preliminary circuit: from 0.00 to 99.99 Switching output: NPN, MOSFET 40V / 2A
RCDL LCR REGISTER MIT IMPULSAUSGANG U. STROMAUSGANG 4-20MA
Electronic counter LCR type with an LCD display, Display 1: resettable totalizer or Flow display programmable, Format xxx.xx. Display 2: Non-resettable totalizer 14 digits. Memory display: EEPROM, data retention in battery replacement Units: liters, gallons, pints, quarts Temperature: 0-70 ° C Pulse acquisition: Reed, max.50Hz Input pulse: from 1.00 to 17000.00 (numerator) Correction factor: 0.5000 to 2.0000 Power supply: 3 VDC Lithium CR 1/2 AA
RCDL LCR REGISTER OHNE IMPULSAUSGANG
Electronic counter LCR type with an LCD display, for the OG series Display 1: resettable totalizer or Flow display programmable, format xxxx.x Display 2: Non-resettable totalizer 14 digits Memory display: EEPROM, data retention in battery replacement Units: liters, gallons, pints, quarts Temperature: 0-70 ° C Pulse acquisition: Reed, max.50Hz Input pulse: from 1.00 to 17000.00 (numerator) Correction factor: 0.5000 to 2.0000 Power supply: 3 VDC Lithium CR 1/2 AA Protection: IP 64
3/4 "or 1" PPO Viton without pulse, fluid meter RCDL M25 without construction. Material and technical data: Housing: Nylon Measuring chamber: Noryl (PPO) O-rings: Viton Measuring range: 1-100 l / min Accuracy: +/- 1.5% of the value p-max: 10 bar t-max: 50 ° C Connection: R 3/4 "or R 1" Installation length: 190 mm Installation position: horizontal, standing
Vectra Viton pulse PFT-2 reed contact Liquid meter RCDL M25 without construction. Materials and technical data: Housing: Bronze Measuring chamber: Vectra O-rings: Viton Measuring range: 3-100 l / min Accuracy: +/- 1.5% of the value p-max: 10 bar t-max: ° C Connection: R 1 "outside Installation length: 190 mm Installation position: horizontal, standing 604011 Pulse PFT-2 reed contact about 52 PPL
liquid meter
RCDL M25 3/4" ODER 1" PPO VITON OHNE IMPULSGEBER
(Liquid meter RCDL M25 without Construction. Material and technical data: Housing: Nylon Measuring chamber: Noryl (PPO) O-rings: Viton Measuring range: 1-100 l / min Accuracy: +/- 1.5% of the value p-max: 10 bar t-max: 50 ° C Connection: R 3/4 "or R 1" Installation length: 190 mm Installation position: horizontal, vertical)
RCDL M25, WITH PULSE- TRANSMITTER PFT-1E - 52,4 PULSE/LITER SETUP
Housing : Bronze Chamber : Noryl (PPO) O-Rings : Buna Flowrange : 1-100 l/min Accuracy : +/- 1,5 % of value p-max : 10 bar t-max : 50 °C Connection : Threads 1" male Laylength : 190mm Pulsoutput : Open Collector NPN Scale Factor : 0.00001 to 0.9999 Supply : 12-24 VDC Pulsoutput : S/N : Part-Nr. 141158
