| BRAND | Demag |
| Product | KBA 80 B 6 B3 1 |
| Description | Cone rotor brake motor |
| Internal code | ONR4682255 |
| Weight | 14 |
| Technical specification | Motor speed 870 rpm Power 0.67 kW Turn-on time 60% IP 54 motor protection class IP 20 brake protection Ambient temperature -20... +40 °C Installation height <= 1000 m KBA 80 B 6 -B3-1 construction key B3 design Right terminal box position, 1 Horizontal motor mounting position Total net weight approx. 14 kg Electrical data: Line voltage D/Y 230/400 V Line frequency 50 Hz Current D/Y 4.80/2.80 A equipment: Light cone brake disc Temperature class F with factory certificate 2.1 according to EN 10204 1-fold Design exactly the same as factory number: 70491200 Execution exactly like order number: 392700 Colouring: RAL 5009, azure blue documentation: Assembly instructions EU documents in accordance with the Machinery Directive The cone rotor brake motor is designed according to our 203 150 44 catalog, which we can provide you with if required gladly provide The motor is designed in accordance with DIN EN 60034-1. Note: The selected motor does not fall within the scope of the EUP Directive |
Please Contact Us to Order to offer best price and delivery time for Demag - KBA 80 B 6 B3 1 Cone rotor brake motor number, also you may ask some other model number is well. We can offer best price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY ORIGINAL AND NEW PRODUCTS!
Our company is not an authorized distributor and manufacturer's representative of the brands shown on the website. Private brand names shown on this site and trademarks are the property of their respective owners
Important note: Although we Demag - Products are Onrion LLC not an authorized dealer. All rights are reserved by the manufacturers and their official partners.
Where can I buy KBA 80 B 6 B3 1 by Demag in United States?
You can purchase KBA 80 B 6 B3 1 by Demag from Onrion LLC. We serve customers across United States, offering competitive prices and reliable service.
What is the price of the KBA 80 B 6 B3 1?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Demag in United States?
While we are not the official distributor or seller of Demag in United States, we source our products from reliable channels and offer you original Demag equipment at competitive prices.
How can I access KBA 80 B 6 B3 1 catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for KBA 80 B 6 B3 1 on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for KBA 80 B 6 B3 1?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
