ESA609 - Fluke United States Sales

BRAND	Fluke
Product	ESA609
Description	Electrical Safety Analyzer
Internal code	ONR4055119
Weight	0.7
Technical specification	Range 90.0 to 264.0 V ac rms Accuracy ± (2 % of reading + 0.2 V) Earth resistance Modes Two wire Test current > 200 mA dc Range 0.000 Ω to 20.000 Ω Accuracy ± (1 % of reading + 0.010 Ω) Resistance tests Earth resistance and point to point Equipment current Mode AC RMS Range 0.0 A to 20.0 A Accuracy ± (5 % of reading + (2 counts or 0.2 A, whichever is greater)) Duty cycle 15 A to 20 A, 5 min on / 5 min off 10 A to 15 A, 7 min on / 3 min off 0 A to 10 A, continuous Leakage current Modes True-RMS Patient load selection AAMI ES1-1993 Fig. 1 IEC 60601: Fig. 15 Crest factor Less than or equal to 3 Ranges 0.0 µA to 1999.9 µA Accuracy DC to 1 kHz ± (1 % of reading + (1 µA , whichever is greater)) 1 kHz to 100 kHz ± (2.5 % of reading + (1 µA, whichever is greater)) 100 kHz to 1 MHz ± (5 % of reading + (1 µA, whichever is greater)) Leakage tests Ground wire earth Chassis (enclosure) Direct equipment Point to point Temperature Operating 0 °C to 50 °C (32 °F to 122 °F) Storage -20 °C to 60 °C (-4 °F to 140 °F) Humidity 10 % to 90 % non-condensing Altitude 120 V ac mains supply voltage 5000 m 230 V ac mains supply voltage 2000 m Display LCD display Modes of operation Manual Power ratings 115 volt power outlet 90 to 132 V ac rms, 47 to 63 Hz, 20 A maximum 230 volt power outlet 180 to 264 V ac rms, 47 to 63 Hz, 16 A maximum Power input 115 V 20 A - 2.6 kVA and 230 V at 16 A - 4.2 kVA

Please Contact Us to Order to offer best price and delivery time for Fluke - ESA609 Electrical Safety Analyzer number, also you may ask some other model number is well. We can offer best price, and delivery time with wide products distribution network in United States Industrial products Market.

WE SELL ONLY ORIGINAL AND NEW PRODUCTS!

Our company is not an authorized distributor and manufacturer's representative of the brands shown on the website. Private brand names shown on this site and trademarks are the property of their respective owners

Important note: Although we Fluke - Products are Onrion LLC not an authorized dealer. All rights are reserved by the manufacturers and their official partners.

Where can I buy ESA609 by Fluke in United States?

You can purchase ESA609 by Fluke from Onrion LLC. We serve customers across United States, offering competitive prices and reliable service.

What is the price of the ESA609?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of Fluke in United States?

While we are not the official distributor or seller of Fluke in United States, we source our products from reliable channels and offer you original Fluke equipment at competitive prices.

How can I access ESA609 catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for ESA609 on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for ESA609?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
