| BRAND | Leybold |
| Product | D65BCS (Part No. 113 98) |
| Description | two stage rotary vane pump |
| Internal code | ONR4670415 |
| Weight | 84.5 |
| Custom code | 84141025 |
| Technical specification | Oil-sealed vacuum pump with integrated oil pump for Forced lubrication of the bearings even at high suction pressures of 1013 mbar. The pump is free of non-ferrous metals and the inner part of the pump is metallically sealed i.e. no use of elastomer Seals that can be chemically damaged. The TRIVAC BCS The pump has a hydropneumatic suction nozzle valve for vacuum protection and via a gas ballast device with which it It is possible to pump condensable vapors. Engine certification: CSA, UR Pump certification: CE RoHS compliant Technical details: Suction speed according to DIN 28400:65 m³/h (50 Hz)/78 m³/h (60 Hz) Final partial pressure without gas ballast: 10-4 mbar Total final pressure with gas ballast: < 5·10-3 mbar Noise level according to DIN 45 635 with/with gas ballast: 57/59 dB (A) Dimensions (LxWxH): 797 x 235 x 361 mm Oil filling min/max: 2.0/ 3.3 l Including oil filling with LVO 100 Weight: 84.5 kg Engine data: Rated power of the three-phase motor 2,2 kW Rated speed: 1460 min-1 (50 Hz)/1760 min-1 (60 Hz) Efficiency class: IE3 Protection class: IP55 200-240 V; 50 Hz; 9.0 A/200-240 V; 60 Hz; 8.8 A 200 V; 50 Hz; 9 A (IE3 = 86.7%) 208-240 V; 60 Hz; 7.8 A (IE3 = 89.5%) 380-400 V; 50 Hz; 4.5 A/400-480 V; 60 Hz; 4.4 A 380-400 V; 50 Hz; 4.5 A (IE3 = 86.7%) 416-480 V; 60 Hz; 3.9 A (IE3= 89.5%) Suitable for line voltages +/- 10% Suction flange: DN40KF can be used horizontally and vertically Outlet flange: DN40KF can be used horizontally and vertically cooling: air equipment: Manual gas ballast setup (on/off) Inert gas connection for gas ballast M16x1.5 Inert gas connection for the M16x1.5 oil box oil drain and oil filler plug |
Please Contact Us to Order to offer best price and delivery time for Leybold - D65BCS (Part No. 113 98) two stage rotary vane pump number, also you may ask some other model number is well. We can offer best price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY ORIGINAL AND NEW PRODUCTS!
Our company is not an authorized distributor and manufacturer's representative of the brands shown on the website. Private brand names shown on this site and trademarks are the property of their respective owners
Important note: Although we Leybold - Products are Onrion LLC not an authorized dealer. All rights are reserved by the manufacturers and their official partners.
Where can I buy D65BCS (Part No. 113 98) by Leybold in United States?
You can purchase D65BCS (Part No. 113 98) by Leybold from Onrion LLC. We serve customers across United States, offering competitive prices and reliable service.
What is the price of the D65BCS (Part No. 113 98)?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Leybold in United States?
While we are not the official distributor or seller of Leybold in United States, we source our products from reliable channels and offer you original Leybold equipment at competitive prices.
How can I access D65BCS (Part No. 113 98) catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for D65BCS (Part No. 113 98) on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for D65BCS (Part No. 113 98)?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
