D 296 - Bosch United States Sales

BRAND	Bosch
Product	D 296
Internal code	ONR4434163
Technical specification	Long-range Beam Smoke Detector 24V Type Number : D 296 Alarm Current (Receiver) 70 Ma Maximum At 24 Vdc Standby Current : Receiver45 mA At 24 Vdc Transmitter: 20 mA at 24 Vdc Operating Voltage : 18.0 Vdc To 32.0 Vdc Alarm Contacts : Normally Open (N/O) contacts rated 1A, 60 V Dc maximum for DC resistive loads, do not use with capacitive or inductive loads Auxiliary Alarm Contacts : Normally Open (N/O) contacts rated 1A, 60 V Dc maximum for DC resistive loads, do not use with capacitive or inductive loads Trouble Contacts : Normally Closed (N/C) contacts rated 1A, 60 V DC maximum for DC resistive loads, do not use with capacitive or inductive loads Environment : Indoor, Dry Relative Humidity : 0% to 95%, non-condensing Temperature (Storage And Operating) : -22°F To +130°F (-30°C To +54°C) For UL listed installations, the range is +32°F to +130°F (0°C to +54°C) Dimensions : 7 In. X 5.5 In. X 5.5 In. (17.8 cm X 14 cm X 14 cm) Mounting Mount : to 3.5 In. Or 4-In. square or octagonal electrical boxes or European Beza boxes Adjustability : Internally adjustable optics for ±90° horizontal, and ±10° vertical adjustment Sensitivity : field selectable for 20%, 30%, 40%, 50%, 60%, or 70% beam obscuration System Signaling : Conventional four-wire system, do not use with systems incorporating an alarm verification feature Signal Delay : Fire: Selectable 30 sec or 5 sec trouble: 20 ± 2 sec Spacing (Distance Between systems) : 60 ft. (18 m) maximum, spacing confirmed by underwriters laboratories (UL) testing Transmission Range : 30 ft. (9 m) to 350 ft. (107 m) Tamper : Receiver: Access Door Tamper Switch In Series With Trouble Contacts. Transmitter: When the cover is removed, the cover tamper switch interrupts transmission

Please Contact Us to Order to offer best price and delivery time for Bosch - D 296 number, also you may ask some other model number is well. We can offer best price, and delivery time with wide products distribution network in United States Industrial products Market.

WE SELL ONLY ORIGINAL AND NEW PRODUCTS!

Our company is not an authorized distributor and manufacturer's representative of the brands shown on the website. Private brand names shown on this site and trademarks are the property of their respective owners

Important note: Although we Bosch - Products are Onrion LLC not an authorized dealer. All rights are reserved by the manufacturers and their official partners.

Where can I buy D 296 by Bosch in United States?

You can purchase D 296 by Bosch from Onrion LLC. We serve customers across United States, offering competitive prices and reliable service.

What is the price of the D 296?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of Bosch in United States?

While we are not the official distributor or seller of Bosch in United States, we source our products from reliable channels and offer you original Bosch equipment at competitive prices.

How can I access D 296 catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for D 296 on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for D 296?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
