BRAND | Lubbering |
Product | 80431801 |
Description | Geared Offset Attachment |
Internal code | ONR4622437 |
Technical specification | Basic-Line 6-43-18-S flat downforce Technical features: type closed max. wrench size 14.29 mm max. output torque 44 Nm max. drive torque 59 Nm efficiency 0.75 gear ratio 1 blade thickness 18 mm wheelbase 70.2 mm radius 14.5 mm gear stages 3 projection length 48.1 mm lubricant Molykote BR2 plus |
Please Contact Us to Order to offer best price and delivery time for Lubbering - 80431801 Geared Offset Attachment number, also you may ask some other model number is well. We can offer best price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY ORIGINAL AND NEW PRODUCTS!
Our company is not an authorized distributor and manufacturer's representative of the brands shown on the website. Private brand names shown on this site and trademarks are the property of their respective owners
default.not_official_distributor_Group5
Pinion shaft
Locking ring 30x1.5
Bearing bushing
Inner ring 17x22x12
Needle bush
Adjusting washer set 25x35x0.1-1
Axial bearing washer 25x42x1
Snap ring 35x1.5
Disc 17x35x1.7
Spindle gear
Idle gear
Idle gear
Idle gear
Needle bush 1 TOOL=2Ea
Needle bush
Needle bush
Axle double step
Axle double step
Axle double step
Axle double step
Lock busher AF 5/64"-AL19
Ring 10x13x0.8
Pawl left L12,9
Spare Part Kit Special-In-Line 0-34-18
Torx cap screw M3x16
Needle roller
Housing, Top part, Special-In-Line 0-34-18
Housing, Bottom Part, Special-In-Line 0-34-18
Gear Hex 14 mm
Lubbering Head
