70640163AY00001 - Lowara United States Sales

BRAND	Lowara
Product	70640163AY00001
Internal code	ONR3356039
Weight	74
Technical specification	Pumptype: LSN 100-65-160 S1VV1 2202 Identical to s/n 60699102 Single stage endsuction pump according to ISO 5199/5199 with enclosed radial impeller. Process design with heavy duty bearing frame for continuous operation with reinforced shaft and bearings. Thrust bearing at drive side, pair of angular contact bearings, roller bearing at pump side. Materials: Impeller : alloy cast steel, 1.4408 Casing : alloy cast steel, 1.4408 casing cover : alloy cast steel, 1.4408 Shaft : alloy steel, 1.4021 shaft sleeve : Stainless Steel Wear rings : without (Standard) Shaft seal: S1..1 Cyclone seal chamber with smooth shaft sleeve Shaft seal MG912 Single seal rubber bellow, unbalanced Materialcombination : BQ1EGG Fluid : Water, pure Temperature : 4 °C Density : 1000,000 kg/m³ Viscosity : 1,569 mm²/s Capacity : 103,0 m³/h Head : 50,0 m Power : 18,2 kW Efficiency : 77,4 % NPSH : 4,16 m Speed : 3550 1/min Req. Motor power : 21,3 kW Suction flange : DN 100, PN16, EN 1092 (IC) horizontal at centerline Discharge flange : DN 65, PN16, EN 1092 (IC) vertical at top-centerline max. Casing pressure : 1600 kPa Suction-/Systempressure : 9,81 kPa Lubrication :Oil (Standard) Oilsump cooling :without Oilsump cooling Constant level oiler :without constant level oiler, with sight glass Labyrinth seals :without Motor Brand : WEG Type : W22 - 180 M - 22kW Nom. power : 22 kW Nom. current : 34,6 A Voltage : 460 V Frequency : 60 Hz Speed : 3540 1/min Design : IM B3 Size : 180 M Isolation class : F Protection class : IP55

Please Contact Us to Order to offer best price and delivery time for Lowara - 70640163AY00001 number, also you may ask some other model number is well. We can offer best price, and delivery time with wide products distribution network in United States Industrial products Market.

WE SELL ONLY ORIGINAL AND NEW PRODUCTS!

Our company is not an authorized distributor and manufacturer's representative of the brands shown on the website. Private brand names shown on this site and trademarks are the property of their respective owners

Important note: Although we Lowara - Products are Onrion LLC not an authorized dealer. All rights are reserved by the manufacturers and their official partners.

Where can I buy 70640163AY00001 by Lowara in United States?

You can purchase 70640163AY00001 by Lowara from Onrion LLC. We serve customers across United States, offering competitive prices and reliable service.

What is the price of the 70640163AY00001 ?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of Lowara in United States?

While we are not the official distributor or seller of Lowara in United States, we source our products from reliable channels and offer you original Lowara equipment at competitive prices.

How can I access 70640163AY00001 catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for 70640163AY00001 on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for 70640163AY00001 ?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
