| BRAND | Leybold |
| Product | 31256TE |
| Description | Two stage rotary vane pump |
| Internal code | ONR4772948 |
| Weight | 37 |
| Custom code | 84141025 |
| Technical specification | Features: Oil-sealed vacuum pump with integrated oil pump for Forced lubrication of bearings The pump is free of non-ferrous metals and the inner part of the pump is metallically sealed, i.e. no use of elastomeric Seals that can be chemically attacked. The TRIVAC T pump is equipped with a gas ballast device, with which makes it possible to pump condensable vapors and via a hydropneumatic suction nozzle valve for vacuum protection. As intended, the vacuum pump must not explode operate in a vulnerable environment. Pump certification: CE RoHS compliant Technical data: Pumping speed in accordance with DIN 28400:14.2 m³/h (50 Hz)/17.0 m³/h (60 Hz) Ultimate total pressure without gas ballast: < 5·10-3 mbar Ultimate total pressure with gas ballast pos. 1: < 8·10-3 mbar Ultimate total pressure with gas ballast pos. 2: < 2·10-2 mbar Sound level according to DIN 45 635 without/with gas ballast: 58/ 60 dB (A) Dimensions (LxWxH): 565 x 195 x 275 mm Oil filling min/max: 1.0/1.6 l Motor data: AC motor rated power: 750 W Rated speed: 1455 min-1 (50 Hz)/1745 min-1 (60 Hz) with on/off switch Protection class: IP54 230 V; 50 Hz; 5.3 A 230 V; 60 Hz; 5.6 A Multipin plug on terminal box, incl. power cable (2 m) with Schuko plug; additional cables optional Suitable for line voltages - 10%/+15% Suction flange: DN25KF vertical Outlet flange: DN25KF vertical Cooling: air equipment: Manual gas ballast device (on/off) oil drain and oil filler plug Package includes: instruction manual Spare parts list 2 x centering and clamping rings Leybonol LVO 130 oil filling |
Please Contact Us to Order to offer best price and delivery time for Leybold - 31256TE Two stage rotary vane pump number, also you may ask some other model number is well. We can offer best price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY ORIGINAL AND NEW PRODUCTS!
Our company is not an authorized distributor and manufacturer's representative of the brands shown on the website. Private brand names shown on this site and trademarks are the property of their respective owners
Important note: Although we Leybold - Products are Onrion LLC not an authorized dealer. All rights are reserved by the manufacturers and their official partners.
Where can I buy 31256TE by Leybold in United States?
You can purchase 31256TE by Leybold from Onrion LLC. We serve customers across United States, offering competitive prices and reliable service.
What is the price of the 31256TE?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Leybold in United States?
While we are not the official distributor or seller of Leybold in United States, we source our products from reliable channels and offer you original Leybold equipment at competitive prices.
How can I access 31256TE catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for 31256TE on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for 31256TE?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
