| BRAND | Mayr |
| Product | mayr® Art.-Nr.: 0013947-1 |
| Description | Cardboard Making Piston |
| Internal code | ONR4704898 |
| Custom code | 84836080 |
| Technical specification | EAS® -axial Reliable overload protection for linear movements 1 364.91 net EAS-axial size 2 Type 300.400 Freehub Hub H1:0 mm Hub H2:0 mm Installation length Length L4:63 mm setting Release force: not set Release force 200 to 500N in accordance with catalog no. K.403.C.V09.DE Design as delivered with mayr® serial number W3106617! |
Please Contact Us to Order to offer best price and delivery time for Mayr - mayr® Art.-Nr.: 0013947-1 Cardboard Making Piston number, also you may ask some other model number is well. We can offer best price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY ORIGINAL AND NEW PRODUCTS!
Our company is not an authorized distributor and manufacturer's representative of the brands shown on the website. Private brand names shown on this site and trademarks are the property of their respective owners
Important note: Although we Mayr - Products are Onrion LLC not an authorized dealer. All rights are reserved by the manufacturers and their official partners.
Where can I buy mayr® Art.-Nr.: 0013947-1 by Mayr in United States?
You can purchase mayr® Art.-Nr.: 0013947-1 by Mayr from Onrion LLC. We serve customers across United States, offering competitive prices and reliable service.
What is the price of the mayr® Art.-Nr.: 0013947-1?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Mayr in United States?
While we are not the official distributor or seller of Mayr in United States, we source our products from reliable channels and offer you original Mayr equipment at competitive prices.
How can I access mayr® Art.-Nr.: 0013947-1 catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for mayr® Art.-Nr.: 0013947-1 on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for mayr® Art.-Nr.: 0013947-1?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
ROBA® - Torque ROBA - slip hub Gr.3 hub Bore: d min = 19mm - d max = 45 mm possible (Please specify while ordering require bore diameter) Fit: H7 Nut: DIN 6885 JS9 Installation Drive element b min = 5 mm / b = 15mm max (Please specify in case of order) Rated torque 250 to 550 Nm according to the catalog number. K. 123. V11.D
ROBA-lastic GR.4 hub Bore: dmin = 25mm / 55mm = dmax Fit H7 = Nut: DIN 6885 BI.1 JS9 pocket part Bore: dmin = 30mm / 75mm = dmax Fit: H7 Nut: DIN 6885 BI.1 JS9 Deputy Schaub thread: no Rated torque 110 to 550Nm
M150 Rotor KO
200-500V ALTERNATIF T= 0.05-2 sec R : 0O-10MO
Brake rectifier
Coupling cone squeeze stars ROP-ES 28
KAPLIN-MAYR-ROBA-RN 4/135-110 H1104259-X0008912
ROBA-stop Gr.6 Solenoid 104V hub Bore: 20 mm Fit: H7 Nut: DIN 6885 BI.1 JS9 Braking torque 26Nm
assembled L05mSK, cable on both sides: (Cable Resolver DD4plug> ACplug SubD9 plug <> round plug 12 pins towing capacity suitable for all PMC-servo controller (DD4, DD5, protego) 5m)
8173908 / AC3.34/0/5/1/1/4/H/3
(Motors, PMCtendo AC3.34 / 0/5/1/1/4 / H / 3 without brake; Feedback System resolver 2-pole, Mo = 2,50Nm Io = 1,72A UN = 400V nN = 3000rpm 1 Jmot = 1,42kgcm2)
Electric motor with brake ROBA topstop
Size 5; disc set, complete Product Code :. 1038004
Metal bellows coupling
backlash-free, torsionally stiff metal smartflex. r.1 Long bellows (8 waves) Reduction 1 Bore: d min = 11mm; d max = 25 mm Fit: H7 Reduction 2 Bore: d min = 11mm; d max = 25mm Pssung: H7 Rated torque 40NM
Smart Flex Cupling
Art. 8180152 20 Type. 017.000.2
ROBA-switch fast acting rectifier size 20 Type 017.000.2 Input voltage 200-500 VAC Output voltage of 90-225 V DC Operation with overexcitation or power reduction Max. current load 1.8 Amp. At <= 45 Celisius ambient temperature 0.9 Amp. At max 70 Celsius ambient temperature Protection IP65 (terminals IP20) Approvals: UL 300V AC to CE according dimension sheet no. M.017. + 002nd D
servo motor coupling
ART.-NR.: 7001225 SMARTFLEX GR.3 TYPE 932.333
Mayr-smartflex - backlash-free, rotationally stripe metal bellows - smartflex Group 3 - 932.333 - bellows long (8Wellen) - Reduction 1 - bore: 25mm - fit: H7 - Reduction 2 - Hole: 25 mm - fit: H7 - nominal torque 200Nm - hole-related, frictionally transferable torque of the shaft / Naber compound; Reduction 1 max. 167Nm at H7 / g6 or comparable fit clearance. Reduction 2 max. 167Nm at H7 / g6 or comparable fit clearance. - according to the catalog number K.932.V10.D.
electromagnetic clutch Size 3, Type 500.200.0 according to the catalog No. K.500.V07.D Coil 24V rotor Bogrung: 25nm Fit: H7 Nut: DIN 6885 BI.1 JS9 Nominal torque 10Nm
COUPLING / 0/100.110/30/6885-3/30 /
ROBA-topstop safety brake size 200 Type 899.000.01.SO
Safety Clutch
EAS-NC GR. 1 TYPE 450.515.0, KONUSBUCHSE, BOHRUNG 25 MM
Backlash-free safety clutch, H7, limit torque on the load 15 to 36 Nm
EAS-NC GR. 3 TYPE 450.515.0, KONUSBUCHSE, BOHRUNG 45 MM
Backlash-free safety clutch, H7, limit torque on load 60 to 150 Nm
EAS-NC GR. 4 TYPE 451.615.0, KONUSBUCHSE, BOHRUNG 50 MM
Backlash-free safety clutch, H7, limit torque for overload 300 to 600 Nm
EAS-NC GR. 4 TYPE 451.615.0, KONUSBUCHSE, BOHRUNG 55 MM
Backlash-free safety clutch, H7, limit torque for overload 300 to 600 Nm
EAS-NC GR.3 TYPE 450.615.0, KONUSBUCHSE, BOHRUNG 45 MM
Backlash-free safety clutch, H7, limit torque on the load 120 to 300 Nm
60/891.020/1S LR108927 180 V 60 Nm, brake
